Máy ép thủy lực CE Máy uốn tấm thép CNC 6100 * 2500 * 4200MM

Thông tin chi tiết sản phẩm

Place of Origin: China

Hàng hiệu: Friendship Machinery

Chứng nhận: CE, ISO

Model Number: FSM-PB

Điều khoản thanh toán & vận chuyển

Minimum Order Quantity: 1

Packaging Details: wooden pallet

Delivery Time: 20 working days

Supply Ability: 30 sets per month

Nhận giá tốt nhất
Làm nổi bật:

cnc hydraulic shearing machine

,

sheet metal bending machine

Mô hình:
WC67Y-600T / 6000
Bộ điều khiển:
E21
Cường độ tấm thép uốn cong:
450N / mm2
Diemension tổng thể:
6100 × 2500 × 4200
Tổng trọng lượng:
52000kgs
Áp suất làm việc của hệ thống thủy lực:
26Mpa
Mô hình:
WC67Y-600T / 6000
Bộ điều khiển:
E21
Cường độ tấm thép uốn cong:
450N / mm2
Diemension tổng thể:
6100 × 2500 × 4200
Tổng trọng lượng:
52000kgs
Áp suất làm việc của hệ thống thủy lực:
26Mpa
Máy ép thủy lực CE Máy uốn tấm thép CNC 6100 * 2500 * 4200MM

1. Overview



● The device adopts all steel-welded construction, and vibratory stress relief. Thus the device with good rigidity and high strength, to permit high accuracy.

● The whole frame with good rigidity, work is stable, safety and reliable, easy to operate.

● To adopt stress theory to control the deformation of structural parts effectively, so can to get satisfied work-piece.

● The workbench adopts bottom cylinder to do deflection compensation, to higher work accuracy.

● Controller: E21 from ESTUN is a cnc controller specialized in torsion axis synchronous press brake machine.





2. Technical parameters



Model Units WC67Y-600T/6000
Controller / E21
The bended steel sheet strength N/mm2 450
Nominal pressure kN 6000
Worktable length mm 6000
The distance between uprights mm 4850
Throat depth mm 400
Ram stroke mm 300
Max opening height between worktable and ram mm 590
Gear pump Model / CP2-100-P-10R
Flow L/min 100
Pressure Mpa 31.5
Ram speed Unloaded mm/s 50
Work mm/s 6
Return mm/s 60
Working Pressure of hydraulic system Mpa 26
Main motor Power kW 45
Electrical system V/Hz 3 phase,380V, 50HZ
Total weight kgs 52000
Overall diemension mm 6100×2500×4200
